Sony PXW-Z300 Camcorder

The Sony PXW-Z300 is a 4K60p shoulder-mount camcorder built for broadcasting and demanding video production. It features three 1/2"-type Exmor R CMOS sensors, the BIONZ XR image processor and a dedicated AI Processing Unit for real-time subject recognition autofocus. With 17x optical zoom, dual CFexpress Type A/SD slots, 12G-SDI output, and flexible LCD placement, it delivers high-quality imaging with field-ready efficiency.

Sony PXW-Z300 Camcorder Key Features:

• Advanced shoulder-mount camcorder with 4K60p recording
• Three 1/2-inch back-illuminated Exmor R CMOS sensors
• Dedicated AI Processing Unit for real-time subject detection
• BIONZ XR processor for fast imaging and accurate colour
• 17x optical zoom lens with constant f1.9 aperture
• 4K 1.5x and HD 4x digital extender with minimal image loss
• Built-in electronic variable ND filter (1/4–1/128)
• High-brightness 3.5-inch LCD with Mini LED backlight
• Dual CFexpress Type A / SD card slots with proxy recording
• Flexible LCD arm for shoulder or front-viewing use
• Side V-Mount with 1/4-inch thread for accessories
• 12G-SDI, HDMI, USB-C PD, LAN, and XLR I/O ports
• Supports RTMP/RTMPS and SRT live streaming
• 4-channel audio recording with individual level dials
• Rugged dust- and moisture-resistant build

Three Exmor R sensors and BIONZ XR processing

At the heart of the PXW-Z300 are three 1/2-inch back-illuminated Exmor R CMOS sensors with full-pixel readout. They capture finely detailed 4K images with a deep depth of field, a wide dynamic range, and low noise, even in challenging lighting conditions. The sensors are matched with Sony’s BIONZ XR image processor, enabling precise colour reproduction and the fast handling of high-resolution footage in real-time.

AI-powered autofocus with subject tracking

The dedicated AI Processing Unit enhances autofocus by recognising human anatomy, posture and orientation. The AI enables precise focus even if a subject is backlit, turned away or wearing a mask. The AF system supports automatic composition to keep human subjects centred in the frame, while Auto Tracing White Balance maintains natural colour in mixed lighting environments.

17x zoom lens with extended digital reach

The integrated 17x zoom lens covers a wide 30.3-515mm (35mm equivalent) focal range at a constant f1.9 aperture. Manual control rings for focus, iris, and zoom ensure tactile control. In HD, a digital extender boosts magnification to 2x, 3x, or 4x; in 4K, it provides up to 1.5x magnification, maintaining image quality while offering reach for dynamic subjects or remote scenes.

Modular connectivity and flexible recording

The PXW-Z300 offers comprehensive connection options including 12G-SDI, HDMI, LAN, USB-C PD, genlock, and dual XLR inputs. It records in XAVC Intra, XAVC Long, MPEG HD422, and proxy MP4 formats to dual CFexpress Type A or SD cards. Slow & Quick Motion, Interval Record, Picture Cache and proxy file transfer via FTP/cloud enable a wide range of production scenarios.

Optimised usability for field production

A high-bright 3.5-inch Mini LED LCD screen with 2.76 million dots offers excellent visibility and can be positioned forward, upward or alongside the optical axis. The side-mounted V-Mount bracket allows tools such as transmitters, phones, or batteries to be attached securely. The rugged chassis features dust and moisture resistance, fan cooling, and tool-free manual adjustments for intuitive operation in fast-paced environments.

What’s in the box?

• 1 x Sony PXW-Z300 Camcorder

FAQs:

Can the Sony PXW-Z300 record in multiple formats simultaneously?

The PXW-Z300 features dual memory card slots that support simultaneous recording of high-resolution MXF footage and lower-resolution proxy MP4 files. These can be used simultaneously for quick previews, editing, or cloud uploads while retaining a full-resolution master.

Does the PXW-Z300 support live streaming?

Yes. It can stream directly to platforms via RTMP/RTMPS and SRT protocols, using either 2.4/5 GHz Wi-Fi or a wired LAN connection. With the optional PDT-FP1 transmitter and Sony’s C3 Portal, it also supports QoS (quality of service) live streaming and remote contribution in professional multi-camera environments.

How does the PXW-Z300 Camcorder’s autofocus system differ from traditional systems?

The PXW-Z300 features a dedicated AI Processing Unit that enhances autofocus accuracy, particularly in challenging scenarios. It can recognise and track people when they are facing away, partially obscured, or at a distance. The system also supports automatic framing to keep subjects centred during dynamic shots.

What power sources are compatible with the PXW-Z300?

The PXW-Z300 Camcorder can be powered by Sony’s BP-U35, BP-U70 or BP-U100 batteries, or through USB-C Power Delivery (PD) with a 100W (20V/5A) AC adapter. The USB-C port has a locking mechanism to prevent accidental disconnection, ensuring uninterrupted shooting in the field.

What is the purpose of the electronic ND filter?

The PXW-Z300 features an internal electronic variable ND filter, allowing for smooth exposure control from 1/4 to 1/128 without adjusting the iris or shutter speed. This feature is beneficial for maintaining consistent brightness when moving between interior and exterior environments.
